Description

BST-100 Pen-Type Gas Soldering Iron

-Brand new and high quality Pen-Type Gas Soldering Iron.

-Model: BST-100

-Material: Plastic

-Working Temperature: 1300 Centigrade

-Instruction:

1. Fill with gas after confirming the switch has been turned off.

2. Fill with gas as picture 1.Lead the gas tank to the filling hole and press to fill.

3. It takes about 10 seconds to complete the filling. Wait several minutes to let the gas be steady before use.

4. Please press the air intake lightly if there is ZIZI noise after filling.

5. Turn on the switch until you hear ZIZI noise as picture 2.

6. Move the flameout ring forward as picture 3.

7. Fire the tip with lighter as picture 4

8. The flame become larger when move to '+', smaller when to '- '.

9. Begin to use when the flame disappears and the tip turns red. The flame should not be too large so as to prolong the service life.

10. The length of the flame is about 12 mm to 15 mm.

Tips

-Please check your model before ordering.

Package Content

1 x BST-100 Pen-Type Gas Soldering Iron

Packing Details

-Weight: 0.07 KG

-Estimated Shipping Weight: 0.14 KG

Specifications

• Weight: 200gr
• Usage: Indoor & outdoor

Pros and cons

• Sustainably produced
• Ideal for everyday use
• May discolor in direct sunlight
